JDK50E1

DESCRIPTION

Fuel dispenser, for fueling station, pumping the oil
Suction pumping unit or submersible type
1 nozzle/2 nozzles/4 nozzles/6nozzles
Gear pump/vane pump/submersible pump
Flow meter
380V motor/ 220V motor
4m/5m/6m hoses
3/4" nozzle/ 1" nozzle
50L/min or 90L/min

Product Description
Accuracy	±0.3%	Inlet Vacuum	≥0.06MPa
Frequency	50HZ+1HZ/60HZ+1HZ	Anti-Explosive ID	Exdm[ib]ib AT3
Delivery Rate	5 to50L/min	Totalizer Range	0.00to99999999999.99
Rating Power	0.75KW	Range of Price	0.01 to99999
Measurbale Minimum	5L	Preset Min Value	0.01 to 0.99L
Ambient Humidity	30% to90%	Power Supply	AC380V±20%&AC220V±20%
Noise	≤80dB(A)	License of Manufacturing	zheZi00000625
Ambient Temperature	-40℃to+60°℃	Anti-Explosive	CE011154
ComponentsInstalled(standard)
1.Electronic Unit
2.Flowmeter
3.Pump
4.Automatic Nozzle
